PULS, LP QS20.361
Manufacturer No: QS20.361
Manufacturer: PULS, LP
Package:
Description: Switch Mode, 13.3A DIN Rail Panel Mount Power Supply Q, 36V dc to 42V dc Dimension
QS20.361 Datasheet
Share
Product Attributes Support
- Factory Lead Time：2 Weeks
- Mount：DIN Rail
- Mounting Type：DIN Rail
- Weight：1.2kg
- Voltage-Input：85V~276VAC
- Operating Temperature：-10°C~70°C With Derating
- Series：DIMENSION Q (480W)
- Size / Dimension：5.00Lx3.23W x 4.88 H 127.0mmx82.0mmx124.0mm
- Part Status：Active
- Moisture Sensitivity Level (MSL)：Not Applicable
- Number of Terminations：9
- ECCN Code：EAR99
- Type：Enclosed
- Applications：Hazardous Locations, ITE (Commercial)
- Power (Watts)：480W
- Terminal Position：UNSPECIFIED
- Terminal Form：UNSPECIFIED
- Peak Reflow Temperature (Cel)：NOT SPECIFIED
- Number of Functions：1
- Depth：24mm
- Time@Peak Reflow Temperature-Max (s)：NOT SPECIFIED
- JESD-30 Code：R-XXMA-X9
- Number of Outputs：1
- Approval Agency：CB, cCSAus, CE, cULus, cURus
- Efficiency：94%
- Voltage - Isolation：500V
- Output Voltage：36V
- Input Voltage-Nom：100V
- Trim/Adjustable Output：YES
- Current - Output (Max)：13.3A
- Output Current：13.3A
- Max Output Voltage：42V
- Min Input Voltage：100V
- Max Input Voltage：240V
- Total Power Output-Max：480W
- Min Output Voltage：36V
- Features：Adjustable Output, Load Sharing, PFC
- RoHS Status：RoHS Compliant
IN STOCK：880
